About this machine
This used Cobert machine is listed as a complete wine bottling line for wine bottling operations. Manufactured in 2008, it is suitable for wineries and beverage producers looking for second-hand equipment for glass bottle production, filling, closure, labelling, packaging or end-of-line handling.
Main specifications: year 2008, speed 3,000 BPH, filling technology Isobaric, clockwise direction and condition As Is. Category: Bottling Lines.
The machine can be evaluated as a standalone unit or as part of a complete used wine bottling line together with fillers, corkers, cappers, capsule machines, labellers, case packers, palletizers and conveyors, depending on the final project requirements.
Current location: Europe. Availability/status: available. Use machine code NP 661 when requesting additional photos, technical data, inspection options, dismantling, loading, transport or installation support.
Original technical notes:
Used Complete Bottling Line for Wine:
Speed: 3.000 bph
Direction: Clockwise
Depalletizer Tmg Vega 60 – 2008
Push System
Rinser Ave Rai 12 – 1999
Number of clamps: 12
Single treatment
Fixed Nozzle
Filler Cobert Suprema – 1985
Number of Filling Valves 24
Type of filling system: Isobaric Filling System
Self-leveling
Degassing
Pre-evacuation
Capper Arol Geini/ rf – 1997
Single head for Natural Straight Cork e Mushroom Cork
Caps Elevator and Orientator Neri – 1990
Capper Kompass Star One Av – 2007
Single head Capper Stelvin 30×60
Wirehooder Nortan Minerva 108 – 1997
Washer-Dryer Cames tnn 1 Air Blade- 2001
Capsuler Nortan Unicap 35 t.s – 1997
Single heads for:
Pvc Capsules
Polylaminate Capsules
Capsuler Nortan omega 3 heads champagne – 1995
Dryer Tunnel – 2017
Labeller P.E. 9T Universal/master/s – 2000
4 adhesive stations
Labeller 5T Cavagnino&Gatti
Number of stations 2 cold glue
Case Packer Monoblock Tmg – 2008
Model Combi 15 n- da
Case Erector
Case Packer
Formats:
3×2
4×3
Hives Inserter
Case Sealer Tape System
Bilance – oma – 2016
Labeller for Boxes
Palletizer millenium 3000 – 2005
Type: Push System
d. 89.20 mm
D. 92/81.8 mm
d. 94.8 mm
D. 97.6 mm
D. 84 mm
Safety protections
